Product: |
Shielded 3+3 Pins 220v 24v Gate Drive Transformer |
Type: |
Gate Drive Transformer |
Appliance: |
High Frequency Transformer |
Mounting:: |
Surface Mount |
Bobbin Material: |
Phenolic |
Color: |
Black, Yellow . Grey |
Product: |
Shielded 3+3 Pins 220v 24v Gate Drive Transformer |
Type: |
Gate Drive Transformer |
Appliance: |
High Frequency Transformer |
Mounting:: |
Surface Mount |
Bobbin Material: |
Phenolic |
Color: |
Black, Yellow . Grey |
Shielded 3+3 Pins 220v 24v Gate Drive Transformer
D Electrical Properties:
| Properties | Test conditions | Value | Unit | Tol. | |
| Inductance | 10 kHz/ 100 mV | L | 260 | μH | min. |
| Leakage inductance | 100 kHz/ 100 mV | LS | 1.7 | μH | max. |
| DC Resistance 1 | RDC | 600 | mΩ | max. | |
| DC Resistance 2 | RDC | 600 | mΩ | max. | |
| DC Resistance 3 | RDC | 600 | mΩ | max. | |
| Turns ratio | n | 1:1:1 | |||
| Voltage-μSecond | B = 280 mT | ∫Udt | 25.2 | μVs | typ. |
| Interwinding capacitance | 100 kHz/ 100 mV | CWW | 9 | pF | typ. |
| Rated voltage | UR | 80 | V (DC) | ||
| Insulation test voltage | UT | 1500 | V (DC) |
E General information:
It is recommended that the temperature of the part does not exceed +125°C under worst case conditions.
Product Picture:
Shielded 3+3 Pins 220v 24v Gate Drive Transformer
