1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer

Product Details

Place of Origin: Guangdong China

Brand Name: Shareway

Certification: CE UL RoHS ISO9001:2008

Model Number: 1812WBT2-2L_

Payment & Shipping Terms

Minimum Order Quantity: 100/500/1000

Price: Supportive

Packaging Details: 2200/reel

Delivery Time: Stock or 3 weeks

Payment Terms: TT,Paypal

Supply Ability: 5000K.PCS/Month

Get Best Price
Highlight:

ferrite core transformer

,

high frequency transformer

Product Name:
1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer
Application:
Office Equipment
Inductance:
5.850 UH
Test Freq.:
10 MHz
Material:
Gold Over Nickel Over Moly-manganese
Skype:
Nickchou80
Product Name:
1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer
Application:
Office Equipment
Inductance:
5.850 UH
Test Freq.:
10 MHz
Material:
Gold Over Nickel Over Moly-manganese
Skype:
Nickchou80
1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer

1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer


APPLICATIONS:

1. VCRS, Copy machine , Audio equipment , Game machines
2. TV sets, Microcomputer equipment, printers, Terminals
3. communications control equipment
4.Switching power supply, chargers, alarm system

5. UPS, VCD/DVD players, audio and visual equipment

6. OA machines, inverters, chargers, alarm system





Core material Ferrite
Terminations RoHS compliant gold over nickel over moly-manganese.
Other terminations available at additional cost.
Weight 131 – 152 mg
Ambient temperature –40°C to +85°C with Irms current
Storage temperature Component: –40°C to +85°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30°C /
85% relative humidity)





Part

number

Inductance

(μH)

Test frequency

(MHz)

Imp. ratio

pri : sec

DCR max

(Ohms)

IDC

(mA)

Isolation

(Vrms)

Insertion

loss (dB)

Bandwidth

(MHz)

Color

dot

1812WBT-1L_ 14 10 1 : 1 4.8 200 50 <1 0.340–22 Yellow
1812WBT-2L_ 5.3 10 1 : 1 1.8 400 50 <1 0.800–60 Green
1812WBT-3L_ 1.25 50 1 : 1 0.7 500 50 <1 4–200 White
1812WBT-4L_ 0.220 50 1 : 1 0.3 700 50 <1 11–480 Orange
1812WBT-5L_ 0.090 50 1 : 1 0.15 700 50 <1.5 48–645 Red





1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer


Shape and Dimensions:

1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer 0





Product picture:

1812WBT2-2L_ 3.81mm*4.52mm*3.43mm SMD SMPS Flyback Transformer 1
