350μH OCL 8mA Bias Gigabit Ethernet Transformer Unshield 40 Pins MOX-LAN-QP4B-1240

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Model Number: MOX-LAN-QP4B-1240

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: Supportive

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 1kk-pcs/month

Get Best Price
Highlight:

gigabit ethernet transformer

,

telecom isolation transformer

Part Number:
350μH OCL With 8mA Bias Magnetic Transformers MOX-LAN-QP4B-1240
Size:
28.4x16.0x5.7mm
Operating Temperature:
-40°C To +85°C.
Pin:
40 Pins
Shield:
Unshield
Inductance:
350uH
Part Number:
350μH OCL With 8mA Bias Magnetic Transformers MOX-LAN-QP4B-1240
Size:
28.4x16.0x5.7mm
Operating Temperature:
-40°C To +85°C.
Pin:
40 Pins
Shield:
Unshield
Inductance:
350uH
350μH OCL 8mA Bias Gigabit Ethernet Transformer Unshield 40 Pins MOX-LAN-QP4B-1240

350μH OCL with 8mA bias Magnetic Transformers MOX-LAN-QP4B-1240


Description:

  Insertion
Loss
Maximum
Return Loss
dB
(Min)
Return Loss
dB
(Min)
Return Loss
dB
(Min)
Return Loss
dB
(Min)
Cross
Talk
dB (Min)
Cross
Talk
dB (Min)
Cross
Talk
dB (Min)
Cross
Talk
dB (Min)
DCMR*
dB (Typ)
DCMR*
dB
(Typ)
Hi-Pot
(Vrms)
Part Number 100KHz~100MHz
(dB Maximum)
2~30
(MHz)
40
(MHz)
50
(MHz)
60~80
(MHz)
1
(KHz)
30
(MHz)
60
(MHz)
100
(MHz)
1~60
(MHz)
60~200
(MHz)
VRMS
Min.
MOX-LAN-QP4B-1240 -1.0 -18 -14.4 -13.1 -12 -65 -50 -40 -35 -40 -35 1500
MOX-LAN-QP4B-1264 -1.0 -18 -14.4 -13.1 -12 -55 -45 -40 -33 -37 -25 1500
MOX-LAN-QP4B-1234 -1.4 -18 -14.4 -13.1 -12 -55 -45 -40 -33 -37 -25 1500
MOX-LAN-QP4B-1241 -1.0 -16.5 -16 -15.5 -12 -60 -43 -38 -33 -43 -27 1500





Dimensions:

350μH OCL 8mA Bias Gigabit Ethernet Transformer Unshield 40 Pins MOX-LAN-QP4B-1240 0
