Product Details
Place of Origin: Guangdong,shenzhen
Brand Name: Shareway
Certification: RoHS,ISO9001-2001
Model Number: EP-389SG
Payment & Shipping Terms
Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel/Tray
Delivery Time: Stock Or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 1kk-pcs/month
Product Name: |
Switching Power Transformer EP-389SG For Cold Cathode Fluorescent Lamp |
Usage: |
Microcomputer Equipment |
Length: |
17.75mm |
Width: |
14.2mm |
Height: |
12.7mm |
Pitch: |
2.5mm |
Product Name: |
Switching Power Transformer EP-389SG For Cold Cathode Fluorescent Lamp |
Usage: |
Microcomputer Equipment |
Length: |
17.75mm |
Width: |
14.2mm |
Height: |
12.7mm |
Pitch: |
2.5mm |
Switching Power Transformer EP-389SG For Cold Cathode Fluorescent Lamp
Electrical Specifications @25 ℃:
| Part Number |
Power (W) |
Vinput (DC) |
Output | Aux/Bias | Drive |
Application (KHz) |
Pri Inductance (uH)±10% |
Leakage Inductance (uH MAX) |
Hi-pot (Vrms) Pri-Sec |
Size W*L*H(mm) |
| EP-427SG | 15.0 | 36-57V | 5.0V,3.0A | / | / | 200 | 40 | 0.65 | 1500 | 17.75*14.2*12.7 |
| EP-704SG | 15.0 | 36-57V | 12V,1.25A | / | / | 200 | 40 | 0.6 | 1500 | 17.75*14.2*12.7 |
| EP-602SG | 15.0 | 36-60V | 5.0V,3.0A | 12V,20mA | / | 250 | 64 | 1.5 | 1500 | 17.75*14.2*12.7 |
| EP-547SG | 15.0 | 36-64V | 54V,0.28A | 13.5V,20mA | / | 250 | 32.4 | 1.0 | 1500 | 17.75*14.2*12.7 |
| EP-546SG | 18.0 | 33-57V | 12V,1.5A | 12V,10mA | / | 250 | 100.5 | 0.9 | 1500 | 17.75*14.2*12.7 |
| EP-527SG | 24.0 | 33-57V | 12V,2.0A | 10V,20mA | 5.0V,10mA | 400 | 90 | 2.0 | 1500 | 17.75*14.2*12.7 |
| EP-421SG | 25.0 | 33-57V | 5.0V,5.0A | 12V,30mA | / | 250 | 37 | 1.0 | 1500 | 17.75*14.2*12.7 |
| EP-475SG | 25.0 | 33-57V | 12V,2.1A | 12.5V,30mA | / | 250 | 38 | 0.5 | 1500 | 17.75*14.2*12.7 |
| EP-197SG | 27.0 | 33-57V | 15V,1.8A | 12V,20mA | / | 200 | 29 | 1.0 | 1500 | 17.75*14.2*12.7 |
| EP-434SG | 30.0 | 33-57V | 12V,2.5A | 15V,20mA | / | 600 | 17.3 | 0.6 | 1500 | 17.75*14.2*12.7 |
| EP-389SG | 30.0 | 33-57V | 12V,2.5A | 12V,10mA | / | 200 | 100.5 | 0.9 | 1500 | 17.75*14.2*12 |
Dimensions:
