Product Details
Place of Origin: Guangdong,shenzhen
Brand Name: Shareway
Certification: RoHS,ISO9001-2001
Model Number: SC53-4R2
Payment & Shipping Terms
Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel/Tray
Delivery Time: Stock Or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 1kk-pcs/month
Product Name: |
SC53-4R2 Electrical Unshielded Inductor SMT Choke Coil Power Inductor |
Material: |
Ferrite |
DC Resistance: |
70mA To 8.8A |
Inductance: |
4.2 To 1000uH |
Current: |
0.13 To 1.85A |
Temperature Current: |
0.17 To 2.6A |
Product Name: |
SC53-4R2 Electrical Unshielded Inductor SMT Choke Coil Power Inductor |
Material: |
Ferrite |
DC Resistance: |
70mA To 8.8A |
Inductance: |
4.2 To 1000uH |
Current: |
0.13 To 1.85A |
Temperature Current: |
0.17 To 2.6A |
SC53-4R2 Electrical Unshielded Inductor SMT Choke Coil Power Inductor
Electrical Chareristics:
| Part Number | Inductance (uH) |
Test Frequency |
DC Resistance (Ω MAX) |
Saturation Current (A) |
Temperature Current (A) |
| SC53-4R2 | 4.2 | 7.96MHZ | 70m | 1.85 | 2.60 |
| SC53-6R2 | 6.2 | 7.96MHZ | 85m | 1.75 | 2.20 |
| SC53-100 | 10 | 2.52MHZ | 0.11 | 1.30 | 1.85 |
| SC53-120 | 12 | 2.52MHZ | 0.13 | 1.23 | 1.60 |
| SC53-150 | 15 | 2.52MHZ | 0.16 | 1.10 | 1.50 |
| SC53-180 | 18 | 2.52MHZ | 0.18 | 1.05 | 1.40 |
| SC53-220 | 22 | 2.52MHZ | 0.23 | 0.93 | 1.30 |
| SC53-270 | 27 | 2.52MHZ | 0.25 | 0.84 | 1.20 |
| SC53-330 | 33 | 2.52MHZ | 0.30 | 0.76 | 1.02 |
| SC53-390 | 39 | 2.52MHZ | 0.35 | 0.68 | 0.95 |
| SC53-470 | 47 | 2.52MHZ | 0.43 | 0.63 | 0.85 |
| SC53-560 | 56 | 2.52MHZ | 0.54 | 0.59 | 0.78 |
| SC53-680 | 68 | 2.52MHZ | 0.59 | 0.53 | 0.70 |
| SC53-820 | 82 | 2.52MHZ | 0.72 | 0.48 | 0.62 |
| SC53-101 | 100 | 1KHZ | 0.92 | 0.45 | 0.56 |
| SC53-121 | 120 | 1KHZ | 1.01 | 0.42 | 0.52 |
| SC53-151 | 150 | 1KHZ | 1.3 | 0.38 | 0.46 |
| SC53-181 | 180 | 1KHZ | 1.6 | 0.35 | 0.40 |
| SC53-221 | 220 | 1KHZ | 1.8 | 0.32 | 0.38 |
| SC53-271 | 270 | 1KHZ | 2.4 | 0.30 | 0.35 |
| SC53-331 | 330 | 1KHZ | 3.2 | 0.28 | 0.31 |
| SC53-391 | 390 | 1KHZ | 3.5 | 0.26 | 0.29 |
| SC53-471 | 470 | 1KHZ | 4.2 | 0.20 | 0.25 |
| SC53-561 | 560 | 1KHZ | 4.9 | 0.19 | 0.22 |
| SC53-681 | 680 | 1KHZ | 6.7 | 0.18 | 0.20 |
| SC53-821 | 820 | 1KHZ | 7.8 | 0.15 | 0.18 |
| SC53-102 | 1000 | 1KHZ | 8.8 | 0.13 | 0.17 |
Dimensions:
