Product Details
Place of Origin: Guangdong,shenzhen
Brand Name: Shareway
Certification: RoHS,ISO9001-2001
Model Number: NRV2012T1R5NGF
Payment & Shipping Terms
Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel/Tray
Delivery Time: Stock Or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 1kk-pcs/month
Part Number: |
NRV2012T1R5NGF Shielded SMD Coupled Inductor For Electronics Computer |
Usage: |
Electronics |
Inductance: |
1.5uH±30%, |
Inductor: |
Coupled Inductor |
Shielded: |
Shielded |
Samples: |
Free |
Part Number: |
NRV2012T1R5NGF Shielded SMD Coupled Inductor For Electronics Computer |
Usage: |
Electronics |
Inductance: |
1.5uH±30%, |
Inductor: |
Coupled Inductor |
Shielded: |
Shielded |
Samples: |
Free |
NRV2012T1R5NGF Shielded SMD Coupled Inductor for Electronics Computer
Description:
| Inductance | 1.5 uH ± 30 % |
| Case Size (mm) | 2.0x2.0 |
| Rated Current (max) | 1.4 A |
| Saturation Current (max) | 1.8 A (⊿L=30%) |
| Saturation Current (typ) | 1.95 A (⊿L=30%) |
| Temperature Rise Current (max) | 1.4 A (⊿T=40℃) |
| Temperature Rise Current (typ) | 1.55 A (⊿T=40℃) |
| DC Resistance (max) | 0.12 Ω |
| DC Resistance (typ) | 0.1 Ω |
| LQ Measuring Frequency | 100 kHz |
| Operating Temp. Range | -25 to +120 ℃ (Including-self-generated heat) |
|
Temperature characteristic (Inductance change) |
± 20 % |
| RoHS Compliance (10 subst.) | Yes |
| REACH Compliance (201 subst.) | Yes |
| Halogen Free | Yes |
Dimensions:
| Dimension L | 2.0 ±0.1 mm |
| Dimension W | 2.0 ±0.1 mm |
| Dimension H | Max 1.2 mm |
| Dimension e | 0.5 ±0.2 mm |
| Dimension f | 1.25 ±0.2 mm |
