Product Details
Place of Origin: China
Brand Name: Shareway
Model Number: S558-5500-72
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: Supportive
Delivery Time: 3~4weeks
Payment Terms: L/C, T/T
Supply Ability: 10000PCS/month
Length: |
27.81±0.25mm |
Width: |
15.24mm |
Height: |
7.24±0.25mm |
Length: |
27.81±0.25mm |
Width: |
15.24mm |
Height: |
7.24±0.25mm |
ELECTTICAL CHARACTERISTICS @25℃
Turns Ratio
PHY:LINE 1CT:1CT ±2%
Polarity PER DOT CONVENTION
DCL @1MHz,100mV
-40℃ to +85℃ 350uH MIN WITH 11mA DC BIAS
-40℃ to +85℃ 120uH MIN WITH 19mA DC BIAS
DC Resistance (1/2 WINDING)0.35 OHM MAX
HIPOT 1500Vrms
