Product Name: |
MSD1514-252MED Surface Mount Magnetic Shielding Power Inductors |
Usage: |
For Flyback Applications |
Mount: |
Surface Mount |
Product Type:: |
Isolated Buck Transformers |
Operating Temperature Range: |
-40 °C Up To +85 °C |
Inductance: |
2 UH |
Package: |
Cut Tape /MouseReel/ Reel |
Product Name: |
MSD1514-252MED Surface Mount Magnetic Shielding Power Inductors |
Usage: |
For Flyback Applications |
Mount: |
Surface Mount |
Product Type:: |
Isolated Buck Transformers |
Operating Temperature Range: |
-40 °C Up To +85 °C |
Inductance: |
2 UH |
Package: |
Cut Tape /MouseReel/ Reel |
MSD1514-252MED Surface Mount Magnetic Shielding Power Inductors
Characteristics
Electrical Properties:
|
Part number
|
Common mode
impedance
max (kOhms)
|
Cutoff
frequency
(MHz)
|
Inductance (µH)
|
DCR max
(Ohms)
|
Isolation
(Vrms)
|
Irms
(A)
|
|
|
min
|
nom
|
||||||
|
MSD1514-252MED
|
2.96 @ 35 MHz
|
10.0
|
2.00
|
2.5
|
0.012
|
500
|
5.10
|
|
MSD1514-472MED
|
4.02 @ 23 MHz
|
18.0
|
3.76
|
4.7
|
0.014
|
500
|
4.50
|
|
MSD1514-103MED
|
6.54 @ 14 MHz
|
17.0
|
8.00
|
10 |
0.018
|
500
|
4.00
|
|
MSD1514-123MED
|
7.83 @ 14 MHz
|
26.0
|
9.60
|
12 |
0.022
|
500
|
3.70
|
|
MSD1514-153MED
|
11.7 @ 11 MHz
|
9.30
|
12.0
|
15 |
0.028
|
500
|
3.40 |
|
MSD1514-223MED
|
17.1 @ 8.10 MHz
|
14.0
|
17.6
|
22 |
0.036
|
500
|
3.00
|
|
MSD1514-273MED
|
17.9 @ 7.20 MHz
|
10.0
|
21.6
|
27 |
0.039
|
500
|
2.95
|
|
MSD1514-333MED
|
22.6 @ 7.10 MHz
|
21.0
|
26.4
|
33 |
0.052
|
500
|
2.55
|
|
MSD1514-473MED
|
47.6 @ 6.40 MHz
|
5.30
|
37.6
|
47 |
0.075
|
500
|
2.20
|
|
MSD1514-683MED
|
37.8 @ 4.30 MHz
|
8.80
|
54.4
|
68 |
0.090
|
500
|
2.00
|
|
MSD1514-104KED
|
59.8 @ 3.70 MHz
|
11.0
|
80.0
|
100
|
0.126
|
500
|
1.65
|
|
MSD1514-224KED
|
85.6 @ 2.50 MHz
|
10.0
|
176 | 220 |
0.287
|
500
|
1.10
|
|
MSD1514-334KED
|
58.0 @ 2.00 MHz
|
7.30
|
264
|
330 |
0.367
|
500
|
0.98
|
|
MSD1514-474KED
|
101.9 @ 1.60 MHz
|
5.30
|
376
|
470 |
0.550
|
500
|
0.77
|
|
MSD1514-105KED
|
157.9 @ 1.10 MHz
|
4.90
|
800 | 1000 |
1.25
|
500
|
0.55
|
Shape and Dimensions:
Product picture:
MSD1514-252MED Surface Mount Magnetic Shielding Power Inductors
