Product Name: |
749014018 Ethernet Magnetic Transformers For IoT Applications |
Usage: |
For IoT Applications |
Mount: |
Surface Mount |
Product Type:: |
Surface Mount Pulse Transformer |
Operating Temperature Range: |
-40 °C Up To +125 °C |
Inductance: |
350 UH |
Package: |
Cut Tape /MouseReel/ Reel |
Product Name: |
749014018 Ethernet Magnetic Transformers For IoT Applications |
Usage: |
For IoT Applications |
Mount: |
Surface Mount |
Product Type:: |
Surface Mount Pulse Transformer |
Operating Temperature Range: |
-40 °C Up To +125 °C |
Inductance: |
350 UH |
Package: |
Cut Tape /MouseReel/ Reel |
749014018 Ethernet Magnetic Transformers for IoT applications
Characteristics
Applications
Electrical Properties:
|
PARAMETER |
TEST CONDITIONS |
VALUE |
|
INDUCTANCE 12-10 |
100kHz,100mVAC,8mADC, Lp |
350uH min. |
|
INDUCTANCE 9-7 |
100kHz,100mVAC,8mADC, Lp |
350uH min. |
|
DIELECTRIC PRI-SEC |
4800Vrms, 1 second |
4000Vrms, 1 minute |
|
TURNS RATIO |
(1-3):(12-10) |
1:1,±2% |
|
TURNS RATIO |
(4-6):(9-7) |
1:1,±2% |
|
INSERTION LOSS |
500k - 100MHz |
-1.2dB max. |
|
RETURN LOSS |
500k - 30MHz |
-18dB min. |
|
RETURN LOSS |
30M- 45MHz |
-15dB min. |
|
RETURN LOSS |
45M - 60MHz |
-13dB min. |
|
RETURN LOSS |
60M - 80MHz |
-10dB min. |
|
CROSSTALK |
1M - 100MHz |
-40dB min. |
|
DCMR |
500k - 100MHz |
-33dB min. |
Shape and Dimensions:
Product picture:
749014018 Ethernet Magnetic Transformers for IoT applications
