Product Name: |
VPT85BA-01A Surface Mount Push Pull SMPS Flyback Transformer |
Usage: |
For Power Supply |
Product Type:: |
Push-Pull Power Transformer |
Operating Temperature Range: |
-40 °C To +125 °C |
Termination Type: |
Surface Mount |
Package: |
Tape Reel |
Product Name: |
VPT85BA-01A Surface Mount Push Pull SMPS Flyback Transformer |
Usage: |
For Power Supply |
Product Type:: |
Push-Pull Power Transformer |
Operating Temperature Range: |
-40 °C To +125 °C |
Termination Type: |
Surface Mount |
Package: |
Tape Reel |
VPT85BA-01A Surface Mount Push Pull SMPS Flyback Transformer
Product features
| Part number | Inductance(uH) | Turn ratio | Volt-second (Vusec) | Dc resistance DCR(Ω) | Isolation voltage | |||
| L1-2 | N1:N2:N3:N4 | 2N1:Bm:Ae | N1:N2:N3:N4 | VDCmin ;IIeak <1mA | Vin(V) | Vout(V) | Power(W) | |
|
VPT85AB-01A
|
54
|
1:1:1.75:1.75
|
7.6
|
0.23:0.23:0.4:0.4
|
1500V
|
3.3
|
5
|
1
|
|
VPT85BA-01A
|
95
|
1:1:0.76:0.76
|
10.7
|
0.32:0.32:0.25:0.25
|
1500V
|
5
|
3.3
|
1
|
|
VPT85BB-01A
|
150
|
1:1:1.11:1.11
|
11.4
|
0.34:0.34:0.38:0.38
|
1500V
|
5
|
5
|
1
|
|
VPT85BB-02A
|
65
|
1:1:1.14:1.14
|
8.9
|
0.27:0.27:0.3:0.3
|
1500V
|
3.3
|
3.3
|
1
|
|
5
|
5
|
2
|
||||||
|
VPT85BD-01A
|
70
|
1:1:2.6
|
9.5
|
0.3:0.3:0.78
|
1500V
|
5
|
12
|
1
|
|
VPT85BF-01A
|
54
|
1:1:4.92
|
7.6
|
0.18:0.18:0.88
|
1500V
|
5
|
24
|
1
|
VPT85BA-01A Surface Mount Push Pull SMPS Flyback Transformer
Shape and Dimensions:
Product picture:
VPT85BA-01A Surface Mount Push Pull SMPS Flyback Transformer
