Product Details
Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008
Model Number: TGMR-380V6LF
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: Supportive
Packaging Details: 500 parts per full reel
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypal
Supply Ability: 5000K.PCS/Month
Product Name: |
SMD SMPS Flyback Transformer For DC/DC Converter TGMR-380V6LF |
Usage: |
For DC/DC Converter |
Product Type:: |
Push-Pull Power Transformer |
Operating Temperature Range: |
-40 °C To +125 °C |
Termination Type: |
Surface Mount |
Package: |
Tape Reel |
Product Name: |
SMD SMPS Flyback Transformer For DC/DC Converter TGMR-380V6LF |
Usage: |
For DC/DC Converter |
Product Type:: |
Push-Pull Power Transformer |
Operating Temperature Range: |
-40 °C To +125 °C |
Termination Type: |
Surface Mount |
Package: |
Tape Reel |
SMD SMPS Flyback Transformer for DC/DC Converter TGMR-380V6LF
Product features
Part Number | Turns Ratio ±3% PRI : SEC | OCL (µH Typical) | PRI DCR (Ω Max) | PRI ET Constant (V-µs Min.) |
TGMR-310V6LF | 1CT:0.5CT | 500 | 0.8 | 18 |
TGMR-330V6LF | 1CT:0.375CT | 500 | 0.8 | 18 |
TGMR-330V6LF | 1CT:0.75CT | 500 | 0.8 | 18 |
TGMR-340V6LF | 1CT:1.33CT | 800 | 0.9 | 22 |
TGMR-350V6LF | 1CT:1CT | 800 | 0.9 | 22 |
TGMR-355V6LF | 1CT:1.5CT | 800 | 0.9 | 22 |
TGMR-360V6LF | 1CT:2CT | 800 | 0.9 | 22 |
TGMR-370V6LF | 1CT:1.6CT | 800 | 0.9 | 22 |
TGMR-380V6LF | 1CT:2.66CT | 800 | 0.9 | 22 |
SMD SMPS Flyback Transformer for DC/DC Converter TGMR-380V6LF
Shape and Dimensions:
Product picture:
SMD SMPS Flyback Transformer for DC/DC Converter TGMR-380V6LF
