Product Details
Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008
Model Number: WB1-1SLD
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: Supportive
Packaging Details: 500 parts per full reel
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypal
Supply Ability: 5000K.PCS/Month
Product Name: |
WB1-1SLD Audio Transformers Signal Transformers Wideband RF Transformers |
Usage: |
For Wideband |
Mount: |
Surface Mount |
Product Type:: |
Audio Transformers Signal Transformers |
Operating Temperature Range: |
-40 °C Up To +85 °C |
Inductance: |
90 UH |
Package: |
Cut Tape /MouseReel/ Reel |
Product Name: |
WB1-1SLD Audio Transformers Signal Transformers Wideband RF Transformers |
Usage: |
For Wideband |
Mount: |
Surface Mount |
Product Type:: |
Audio Transformers Signal Transformers |
Operating Temperature Range: |
-40 °C Up To +85 °C |
Inductance: |
90 UH |
Package: |
Cut Tape /MouseReel/ Reel |
WB1-1SLD Audio Transformers Signal Transformers Wideband RF Transformers
Characteristics
Electrical Properties:
|
SM
part number
|
TH
part number
|
Imp
ratio
|
Bandwidth
(MHz)
|
Pins 4–6 |
Pins 1–3 | ||
|
L min
(µH) |
DCR max
(mOhms)
|
L min
(µH)
|
DCR max
(mOhms)
|
||||
|
WB1-1SLD
|
WB1-1L
|
1 : 1
|
0.150 - 500
|
27
|
75
|
27
|
75
|
|
WB1-6SLD
|
WB1-6L
|
1 : 1
|
0.100 - 350
|
25
|
100
|
25
|
100 |
|
WB1.18-3SLD
|
WB1.18-3L
|
1 : 1.18
|
0.040 - 300
|
90 |
300
|
108
|
330
|
|
WB1.5-6SLD
|
WB1.5-6L
|
1 : 1.5
|
0.050 - 325
|
56 |
120
|
84 | 150 |
|
WB2-1-2WSLD
|
WB2-1-2WL
|
1 : 2
|
0.080 - 700
|
38 |
100
|
75 | 150 |
|
WB2.5-6SLD
|
WB2.5-6L
|
1 : 2.5
|
0.080 - 225
|
30 |
100
|
75 | 130 |
|
WB4-6SLD
|
WB4-6L
|
1 : 4
|
0.100 - 125
|
25
|
100
|
100 |
200
|
|
WB9-1SLD
|
WB9-1L
|
1 : 9
|
0.125 - 125
|
25
|
100
|
225 |
250
|
|
WB16-1SLD
|
WB16-1L
|
1 : 16
|
0.050 - 100
|
56 |
75
|
896
|
330
|
|
WB36-1SLD
|
WB36-1L
|
1 : 36
|
0.100 - 45
|
25
|
50 |
900
|
180 |
|
WB1-1TSLD
|
WB1-1TL
|
1 : 1
|
0.100 - 375
|
100
|
100
|
25
|
100
|
|
WB1-6TSLD
|
WB1-6TL
|
1 : 1
|
0.050 - 200
|
150 |
150
|
70 |
150
|
|
WB2-1TSLD
|
WB2-1TL
|
1 : 2
|
0.070 - 400
|
100
|
100
|
75 |
150
|
|
WB2.5-6TSLD
|
WB2.5-6TL
|
1 : 2.5
|
0.050 - 125
|
120
|
120
|
140
|
200
|
|
WB3-1TSLD
|
WB3-1TL
|
1 : 3
|
0.040 - 500
|
110
|
110
|
270
|
200
|
|
WB4-1HSLD
|
WB4-1HL
|
1 : 4
|
0.010 - 500
|
120
|
120
|
100 |
160
|
|
WB4-6TSLD
|
WB4-6TL
|
1 : 4
|
0.050 - 200
|
120
|
120
|
172
|
160
|
|
WB5-1TSLD
|
WB5-1TL
|
1 : 5
|
0.050 - 400
|
220
|
220
|
240
|
500 |
|
WB8-1TSLD
|
WB8-1TL
|
1 : 8
|
0.150 - 400
|
100 | 100 | 144 |
270
|
|
WB13-1TSLD
|
WB13-1TL
|
1 : 13
|
0.150 - 125
|
90 | 90 | 221 |
200
|
|
WB16-6TSLD
|
WB16-6TL
|
1 : 16
|
0.050 - 100
|
75 | 75 |
896
|
330
|
|
WBT1-6SLD
|
WBT1-6L
|
1 : 1
|
0.040 - 200
|
150
|
150
|
70
|
150
|
|
WBT1.5-1SLD
|
WBT1.5-1L
|
1 : 1.5
|
0.040 - 350
|
150
|
150
|
70
|
180
|
|
WBT2.5-6SLD
|
WBT2.5-6L
|
1 : 2.5
|
0.050 - 100
|
150
|
150
|
175 |
200
|
|
WBT4-1SLD
|
WBT4-1L
|
1 : 3
|
0.040 - 150
|
120
|
120
|
135
|
160 |
|
WBT4-1ASLD
|
WBT4-1AL
|
1 : 4
|
0.040 - 350
|
110 |
110
|
384
|
220
|
|
WBT16-1SLD
|
WBT16-1L
|
1 : 16
|
0.100 - 100
|
100
|
100
|
400
|
300
|
|
WBT25-1SLD
|
WBT25-1L
|
1 : 25
|
0.100 - 65
|
100
|
100
|
625
|
350
|
Shape and Dimensions:
Product picture:
WB1-1SLD Audio Transformers Signal Transformers Wideband RF Transformers
