LED Light Switch Mode Transformer Laminated Magnetic Core

LED Light Switch Mode Transformer Laminated Magnetic Core
LED Light Switch Mode Transformer Laminated Magnetic Core LED Light Switch Mode Transformer Laminated Magnetic Core

Large Image :  LED Light Switch Mode Transformer Laminated Magnetic Core

Product Details:

Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS

Payment & Shipping Terms:

Minimum Order Quantity: 100/500/1000
Price: Supportive
Packaging Details: reel
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal
Supply Ability: 1000K.PCS/Month
Detailed Product Description
Product Name: Laminated Core Switch Mode Transformer Used For LED Light Core Material:: Magnetic
Type: EFD/ETD/EP/PQ/EE Coil Structure:: Toroidal
Coil Number:: Autotransformer Sample: Free Samples Available
High Light:

6 pin transformer

,

small isolation transformer

Laminated Core Switch Mode Transformer Used for LED Light


Properties Test conditions   Value Unit Tol.
Inductance Base 100 kHz/ 100 mV LBASE 27.4 μH ±20%
Turns Ratio   n 1:1:1:1:1:1
Voltage-μSecond Base   ∫Udt Base 49.3 μVs max.
Rated Current Base ΔT = 40 K IR BASE 0.5 A typ.
Saturation Current Base |ΔL/L| < 10 % ISAT BASE 0.29 A typ.
DC Resistance Base @ 20 °C RDC BASE 344 max.
Leakage Inductance
Base
100 kHz/ 100 mV LS BASE 0.3 μH typ.
Insulation Test Voltage N1,2,3 => N4,5,6 UT 1 1500 V (AC)
Insulation Test Voltage N1 => N2,3; N2 => N3 UT 2 1000 V (AC)
Insulation Test Voltage N4 => N5,6; N5 => N6 UT 3 1000 V (AC)





General Information:

It is recommended that the temperature of the component does not exceed +125°C under worst
case conditions

  • Operating Temperature -40 °C up to +125 °C
  • Storage Temperature (in original packaging) -40 °C up to +85 °C
  • Test conditions of Electrical Properties: +20°C, 33% RH if not specified differently



Laminated Core Switch Mode Transformer Used for LED Light


HOW TO ORDER
1. Please send me your datasheet or part number you need.
2. We will offer the replacement quotation for your reference
3. The free samples are available for your approval.
4. After sample testing, we will step into the mass order.
5. The Proforma Invoice will send for your confirmation
6. After the goods finished, we send the goods to you and tell you the tracking number.
7. We will track your goods until you receive the goods.

Remarks:
1. Sample orders are avaliable.
2. Price is negotiable for orders of large quantity.
3. Customized orders (OEM/ODM orders) are avaliable.
4. Contact us for available flavors list. International Certifications:
