We are using Ethernet every day, whether by RJ45 cable or WIFI. Do you guys ever think about how to manufacture a Shielded RJ45 Jack with Magnetic built inside and LEDs? Well, let me take you on the tour. Step 1. Manufacturing the metal shielding. It's usually made of copper or Iron. Different dimensions, with or without EMI finger. Usually, the factory has tooling to do that job. What we need to know is that copper is better than Iron, except the cost is a bit higher. Step 2. Manufacturing the plastic part, most of which is black. It also uses tooling with injection craft to finish the job. Step 3. Creating the magnetic, it is a coil with many different turns of wires. Then solder it on the PCB board, which will be inserted into the plastic part later. This is also the most labor costed craftwork. Step 4. Choose suitable LED, popular LEDs have Green color, Yellow colors. As we know LED has two different lengths of legs, the longer one is the positive side, and the shorter one is the negative side. But in the RJ45 jack, LED has the same length legs, hence we need cut legs and bend them. Shareway uses auto machines to do it, which could get better performance on the cutting and bending, also save human powers. Step 5. Assembly all the parts. In this step, we will insert the PCB with coils into the plastic modular, then use epoxy to fix them. Assembly the LEDs, then cover them with the metal shield. Step 6. Testing and Marking. Put the RJ45 Jack on the tray and test the function by hand or by machines. The NG part will be picked out for checking and fixing. The passed part will be sent to put marking.   Step 7. Packing and putting on the label. Good packing is something very important, it could protect the products during the shipping way. Shareway has extra testing of the packing, just to make sure customers will get the goods in good condition. We will put the label on the carton box.   About us: Shareway Technology is a leading manufacturer of Magnetic passive components, including RJ45 Magjack, SMD & Thorugh hole Chokes, SMD Power Inductors, and Power Transformers. We are also offering sourcing services for hard-to-find parts. For more information, you are welcome to text me or visit our site at www.shareway-tech.com and www.smpsflybacktransformer.com

750811291 OFFLINE XFRM For AC/DC Converters, LED Drivers, AC/DC SMPS, design for LT3799  Type For AC/DC Converters Applications Flyback Converters Intended Chipset LT3799 Voltage – Primary 85 ~ 265V Voltage – Auxillary 20V @ 10mA Voltage – Isolation 4500Vrms Frequency – Operating Temperature -40°C ~ 125°C Mounting Type Through Hole Size / Dimension 31.00mm L x 31.00mm W Height – Seated (Max) 25.00mm Chipset Manufacturer Linear Technology

We are now releasing our brand new PLC (Power Line Communication ) transformer, Part number ST5001NL.   ST5001NL is a transformer with 1:1 trun ratios , OCL 500uH~160uH @ 100KHz / 5mVrms . which is suitable for PLC Power control board application . This transformer has a high Isolation voltage, which is 4500Vrms 2mA in 3 Seconds.      What is Power Line Communication? Power Line Communication or short for PLC is a communication method of the power supply and data transfer take place at the same time on one cable. PLC also comes up in connection with terms such as  “IoT“ and “Smart Home“.  This involves the interaction between EVs, PHEV,  and the charging stations, which is known as the electric vehicle supply equipment. Since 2014, ISO/IEC 15118-5  has made the framework for the intelligent AC and DC charging of EVs. According to these standards, HomePlug Green PHY™ (HPGP) is scheduled as the standard for the PLC data transfer during plug-in charging.     Solution for EVs Charging     Electrical Vehicles Charging requires critical power, especially at peak times, this can cause particular challenges to grid utilization. This makes it very important for the info to went through via the charging cable to the network operator, which includes the charging time that we wanted, the real-time status, roaming information. From Shareway we offer two special solutions for these coupling transformers.         For more please feel free to contact us, we are available 7x24h to Share our successful Way with you.
