Product Details
Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS
Model Number: 23Z91SMFNL
Payment & Shipping Terms
Minimum Order Quantity: 100/500/1000
Price: Supportive
Packaging Details: reel
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal
Supply Ability: 1000K.PCS/Month
Product Name: |
23Z91SMFNL 1000 BASE-T Single Port Ethernet Magnetic Transformers |
Usage: |
Electronic |
Coil Number: |
Autotransformer |
Phase: |
Single |
Coil Structure: |
Toroidal |
Speed: |
10/100Base-T |
Sample: |
4pcs Free Samples |
Product Name: |
23Z91SMFNL 1000 BASE-T Single Port Ethernet Magnetic Transformers |
Usage: |
Electronic |
Coil Number: |
Autotransformer |
Phase: |
Single |
Coil Structure: |
Toroidal |
Speed: |
10/100Base-T |
Sample: |
4pcs Free Samples |
23Z91SMFNL 1000 BASE-T Single Port Ethernet Magnetic Transformers
PRODUCT DETAILS:
A. J-STD-002: SOLDERABILITY AT 245℃ REFLOW PROFILE
B. J-STD-020: LEVEL 1, NO MOISTURE SENSITIVE
C. J-STD-075: R7, 245℃ MAXIMUM THROUGH REFLOW SOLDER
ELECTRICAL CHARACTERISTICS AT +25℃ UNLESS OTHER SPECIFIED
| PARAMETER | SPECIFICATIONS |
| OPERATING TEMPERATURE | 0℃ TO +70℃ |
| TURNS RATIO | 1 : 1 ±2% |
| POLARITY | PER SCHEMATIC |
| CAPACITANCE WINDING TO WINDING | 10 pF MAX ( AT 100 KHz 20 mVRMS) |
| DC RESISTANCE | 0.3 OHMS MAX |
| LEAKAGE INDUCTANCE | 0.2 uH MAX ( AT 100 KHz 20 mVRMS ) |
| PRIMARY INDUCTANCE | 100uH ±20% ( AT 100 KHz 20 mVRMS ) |
| INPUT -OUTPUT ISOLATION | 1500 VRMS FOR 60 SECONDS |
23Z91SMFNL 1000 BASE-T Single Port Ethernet Magnetic Transformers
HOW TO ORDER
1. Please send me your datasheet or part number you need.
2. We will offer the replacement quotation for your reference
3. The free samples are available for your approval.
4. After sample testing, we will step into the mass order.
5. The Proforma Invoice will send for your confirmation
6. After the goods finished, we send the goods to you and tell you the tracking number.
7. We will track your goods until you receive the goods.
Remarks:
1. Sample orders are avaliable.
2. Price is negotiable for orders of large quantity.
3. Customized orders (OEM/ODM orders) are avaliable.
4. Contact us for available flavors list. International Certifications:
1. ISO9001:2008
2. UL
3. Reach
4. RoHs
Our service:
1. 100% tested before shipping
2. Have alternative for Halo, Pluse, , We-online, Chilisin, Coilcraft......Same quality but better price
3. Free sample available
4. Provide new design for customer
