| Product Name: | PA3019NL EP7 EP10 EP13 High Frequency Power Over Ethernet Transformer | Type: | Power Over Ethernet Transformer |
|---|---|---|---|
| Shape: | Axial | Bobbin: | EP Series |
| Store Humidity: | 30 To 95% | Applications: | Monitor,audio,VCD,DCD ,etc. |
| Highlight: | toroidal coil transformer,8 pin transformer |
||
PA3019NL EP7 EP10 EP13 High Frequency Power Over Ethernet Transformer
Feature:
| Electrical Specifications @ 25°C - Operating Temperature -40°C to +130°C | |||
| PA1130NL | Pri. Inductance | (3-4) | 47.2 μH ±5% |
| Lk. Inductance | (3-4) with (1, 2, 8, 7, 6, 5) shorted |
0.7 μH MAX | |
| DCR | (3-4) | 250mΩ MAX | |
| (6, 5-8, 7) | 72mΩ MAX | ||
| (2-1) | 170mΩ MAX | ||
| Hi-Pot | Pri-Sec | 500Vrms | |
| K1 Factor | 1838.0 | ||
| PA1131NL | Pri. Inductance | (3-4) | 56.7μH ±10% |
| Lk. Inductance | (3-4) with (8, 7, 6, 5) shorted |
0.98 μH MAX | |
| DCR | (3-4) | 400mΩ MAX | |
| (6, 5-8, 7) | 200mΩ MAX | ||
| (2-1) | 110mΩ MAX | ||
| Hi-Pot | Pri-Sec | 500Vrms | |
| K1 Factor | 1766.4 | ||
| PA1132NL | Pri. Inductance | (3-4) | 48.8μH ±10% |
| Lk. Inductance | (3-4) with (8, 7, 6, 5) shorted |
0.4μH MAX | |
| DCR | (3-4) | 100mΩ MAX | |
| (6, 5-8, 7) | 200mΩ MAX | ||
| (2-1) | 110mΩ MAX | ||
| Hi-Pot | Pri-Sec | 500Vrms | |
| K1 Factor | 3040.5 | ||
Product Picture:
