Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules

Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules
Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules

Large Image :  Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules

Product Details:

Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008
Model Number: H1300NL

Payment & Shipping Terms:

Minimum Order Quantity: 100/500/1000
Price: Supportive
Packaging Details: Tray or Reel
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal
Supply Ability: 5000K.PCS/Month
Detailed Product Description
Product Name: Power Electrical Lan Transformer H1300NL Single Port Magnetic Modules Speed: 100 BASE-TX
Core Quantity: 2 Sets Usage: Audio
PIN Quantity: 16 Mounting Type: SMT
High Light:

small electric transformer

,

smd power transformer

power electrical Lan Transformer H1300NL Single Port Magnetic Modules


Description:

Size: 12.7*7.11*5.97mm

Core No. : 2

Pin No. : 16

Inductance : 350 uH MIN

Type : lan transformer

Speed: 10/100Base-T

Hi-pot :1500Vrms





PARAMETER SPECIFICATIONS
OPERATING TEMPERATURE 0 - 70
TURNS RATIO 1 :1 ±2%
POLARITY PER SCHEMTIC
INSERTION LOSS 100KHz 1-125 MHz
-1.2 dB MAX -0.2 -0.002*f ^1.4 dB MAX

RETURN LOSS

(Z OUT = 100 OHM ±15%)

1-30MHz 30-60HMz 60-80MHz
-16 dB MIN

-10+20*LOG10

(f/60 MHz) dB MIN

-10 dB MIN

INDUCTANCE(OCL)

(MEDIA SIDE, 0 -70 )

350 uH MIN(MEASUREN AT 100KHz,100mVRMS AND WITH 8mA DC BIAS)

CROSSTALK, ADJACENT

CHANNELS

1MHz 10-100MHz
-50 dB MIN -50+22*LOG 10(f/10) dB MIN
DIFFERENTIAL TO COMMON MODE REJECTION 2 MHz 30-200MHz
-50 dB MIN -15+20*LOG 10(f/10) dB MIN

DC RESISTANCE

1/2 WINDING

.65 OHMS MAX

DC RESISTANCE

IMBALANCE

.065 OHMS MAX (CENTER TAP SYMMETRY)

INPUT -OUTPUT

ISOLATION

1500 VRMS MIN @ 60 SECONDS





power electrical Lan Transformer H1300NL Single Port Magnetic Modules


Shape and Dimensions:

Power Electrical SMT Transformer H1300NL Single Port Magnetic Modules 0
