Product Details
Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008
Model Number: MOX-HCPI-2818-3R3M
Payment & Shipping Terms
Minimum Order Quantity: 100/500/1000
Price: Supportive
Packaging Details: Tray
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal,
Supply Ability: 3000K.PCS/Month
Product Name: |
27.9*27.9*17.8mm 3.3uH Flat Wire Winding Common Mode Choke For PCB |
Application: |
PCB |
Size: |
27.9*27.9*17.8mm |
Type: |
Flat Inductor |
Inductance: |
3.3-33uH |
Sample: |
Free Sample |
Product Name: |
27.9*27.9*17.8mm 3.3uH Flat Wire Winding Common Mode Choke For PCB |
Application: |
PCB |
Size: |
27.9*27.9*17.8mm |
Type: |
Flat Inductor |
Inductance: |
3.3-33uH |
Sample: |
Free Sample |
27.9*27.9*17.8mm 3.3uH Flat wire winding Common Mode Choke For PCB
Description:
| PART NUMBER | INDUCTANCE (μH) |
TOLERANCE | DCR (mΩ) NOM / MAX |
ISAT (A) DROP ≤ 30% |
IRMS (A) RISE ≤ 40°C |
| MOX-HCPI-2818-3R3M | 3.30 | 20% | 2.60 / 2.86 | 92.50 | 28.00 |
| MOX-HCPI-2818-4R7M | 4.70 | 20% | 2.60 / 2.86 | 61.20 | 28.00 |
| MOX-HCPI-2818-6R8M | 6.80 | 20% | 2.60 / 2.86 | 45.00 | 28.00 |
| MOX-HCPI-2818-100M | 10.00 | 20% | 2.60 / 2.86 | 21.40 | 28.00 |
| MOX-HCPI-2818-150M | 15.00 | 20% | 2.60 / 2.86 | 21.20 | 28.00 |
| MOX-HCPI-2818-220M | 22.00 | 20% | 2.60 / 2.86 | 14.00 | 28.00 |
| MOX-HCPI-2818-330M | 33.00 | 20% | 2.60 / 2.86 | 8.70 | 28.00 |
27.9*27.9*17.8mm 3.3uH Flat wire winding Common Mode Choke For PCB
Shape and Dimensions:
