Smd Emi Shielded Smd Power Inductors Suppression Ferrite Bead

Product Details

Place of Origin: Guangdong China

Brand Name: Shareway

Certification: CE UL RoHS ISO9001:2008

Payment & Shipping Terms

Minimum Order Quantity: 100/500/1000

Price: Supportive

Packaging Details: Reel

Delivery Time: Stock or 3 weeks

Payment Terms: TT,Paypal

Supply Ability: 3000K.PCS/Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                dc dc converter inductor, high current power inductors


Product Name:	SMD Power Inductor Smd Emi Suppression Ferrite Bead	Type:	Smd Emi Suppression Ferrite Bead
Operating Temperature:	-55 TO +125 C	Mount:	Surface Mount
Shape:	Square	Rated Current:	500mA

Product Name:	SMD Power Inductor Smd Emi Suppression Ferrite Bead
Type:	Smd Emi Suppression Ferrite Bead
Operating Temperature:	-55 TO +125 C
Mount:	Surface Mount
Shape:	Square
Rated Current:	500mA

Smd Emi Shielded Smd Power Inductors Suppression Ferrite Bead

SMD Power Inductor smd emi suppression ferrite bead

Description:

The common mode inductor (Common mode Choke), also known as the common mode choke, is a symmetrical coil that turns the same direction in the closed loop. The ideal common mode choke has an inhibitory effect on the common mode interference between L (or N) and E, but the differential mode interference between L and N has no inductance suppression. However, the incomplete symmetry of the actual winding will lead to differential mode leakage inductance. The signal current or power supply current is reversed in the two windings, and the magnetic flux produced is offset by each other. The choke has low impedance. The common mode noise current (including the interference current caused by the ground loop, also called the longitudinal current) is the same direction in the direction of the two windings. The flux generated by the same direction is added to the same direction, and the choke ring presents a high impedance, thus suppressing the common mode noise.

Electrical Properties:

Properties	Test conditions		Value	Unit	Tol.
Impedance @ 100 MHz	100 MHz	Z	100	Ω	±25%
Maximum Impedance	500 MHz	Z	180	Ω	typ.
Rated Current	ΔT = 20 K	IR	500	mA	max.
DC Resistance		RDC	0.3	Ω	max.
