SMD Power Inductor Non Shielded Winding Wire Coil With RoHS Certification

I have had excellent support from Nick Chou at Shareway. We purchased some parts from him and he delivered the products on time and without incident.

—— Phil Hale -- CEO of PSwitches

I have worked with Nick Chou at Shareway for more than 5 years. The most impressive thing is you can always get quick response from him .

—— David Rosero -- CEO of Isolution Service Center

Hi, I am more than happy to confirm your quality is great and your overall business handle is top notch. You have always been an excellent and very accommodating company to us. If you need me to speak directly to them I am more than happy to do so.

—— Paul Harris-- CEO of AuroraMultimedia

I'm Online Chat Now

SMD Power Inductor Non Shielded Winding Wire Coil With RoHS Certification

SMD Power Inductor Non Shielded Winding Wire Coil With RoHS Certification
SMD Power Inductor Non Shielded Winding Wire Coil With RoHS Certification

Large Image :  SMD Power Inductor Non Shielded Winding Wire Coil With RoHS Certification

Product Details:

Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008

Payment & Shipping Terms:

Minimum Order Quantity: 100/500/1000
Price: Supportive
Packaging Details: Reel
Delivery Time: Stock or 3 weeks
Payment Terms: TT,Paypal
Supply Ability: 3000K.PCS/Month
Detailed Product Description
Product Name: Non-shielded Winding Wire Power Inductor Coil With RoHS Inductance: 12uH
Length: 4.5mm Width: 4.0mm
Height: 3.2mm Rated Current: 1.28A
High Light:

dc dc converter inductor

,

high current power inductors

Non-shielded winding wire power inductor coil with RoHS


Description:

  1. winding wire power inductor coil
  2. smd coil / ferrite shield inductor coil
  3. SMD power inductor
  4. Choke coil smd shielded power inductor
  5. Unshielded SMD choke coil filter Power Inductor



Profile Feature Pb-Free Assembly Sn-Pb Assembly
Preheat
- Temperature Min (Tsmin)
- Temperature Max (Tsmax)
- Time (ts) from (Tsmin to Tsmax)
150°C
200°C
60-120 seconds
100°C
150°C
60-120 seconds
Ramp-up rate (TL to TP) 3°C/ second max. 3°C/ second max.
Liquidous temperature (TL)
Time (tL) maintained above TL
217°C
60-150 seconds
183°C
60-150 seconds
Peak package body temperature (Tp) See Table H3 See table H3
Time within 5°C of actual peak temperature (tp) 30 seconds 20 seconds
Ramp-down rate (TP to TL) 6°C/ second max. 6°C/ second max.
Time 25°C to peak temperature 8 minutes max 6 minutes max.





E General information:
It is recommended that the temperature of the part does not exceed 125°C under
worst case operating conditions.
• Ambient temperature: -40°C to +85°C (refering to IR)
• Operating temperature: -40°C to +125°C
• Storage temperature (on tape & reel): -20°C to +40°C; 75% RH max.
• Coplanarity of the terminal pads: 120μm
• Test conditions of Electrical Properties: 20°C, 33% RH
• AEC-Q 200 qualified
