1µH Unshielded Wirewound High Power Inductor 4A Surface Mounting Ferrite
1µH Unshielded Wirewound High Power Inductor 4A Surface Mounting Ferrite
1µH Unshielded Wirewound High Power Inductor 4A Surface Mounting Ferrite

1µH Unshielded Wirewound High Power Inductor 4A Surface Mounting Ferrite

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: Supportive

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 1kk-pcs/month

Get Best Price

Product Details

Product Description
Highlight:

wire wound chip inductors

,

high current power inductors

Product Name:
SMD Power Inductor 1µH Unshielded Wirewound Inductor 4A
Material - Core:
Ferrite
Type:
Wirewound
Inductance:
1µH
Shielding:
Unshielded
Mounting Type:
Surface Mount
Product Name:
SMD Power Inductor 1µH Unshielded Wirewound Inductor 4A
Material - Core:
Ferrite
Type:
Wirewound
Inductance:
1µH
Shielding:
Unshielded
Mounting Type:
Surface Mount
1µH Unshielded Wirewound High Power Inductor 4A Surface Mounting Ferrite

SMD Power Inductor 1µH Unshielded Wirewound Inductor 4A

Description :

Type Wirewound
Material - Core Ferrite
Inductance 1µH
Tolerance ±20%
Current Rating (Amps) 4A
Current - Saturation 5.72A
Shielding Unshielded
DC Resistance (DCR) 49 mOhm Max
Q @ Freq -
Frequency - Self Resonant 110MHz
Ratings AEC-Q200
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 10kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 4532
Size / Dimension 0.177" L x 0.157" W (4.50mm x 4.00mm)
Height - Seated (Max) 0.138" (3.50mm)





Product picture:

1µH Unshielded Wirewound High Power Inductor 4A Surface Mounting Ferrite 0

Tags:

high current power inductors,

wire wound chip inductors,

dc dc converter inductor
