Single Port Ethernet Isolation Transformer G3601DG / G3614DG T1/E1 Application

Name: Single Port Ethernet Isolation Transformer G3601DG / G3614DG T1/E1 Application
Brand: SHAREWAY TECHNOLOGY CO., LTD.
SKU: G3601DG / G3614DG
Price: 0.30 USD
Availability: InStock

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Model Number: G3601DG / G3614DG

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: Supportive

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 1kk-pcs/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                telecom isolation transformer, gigabit ethernet transformer


Product Name:	G3601DG / G3614DG Isolated Single Port Transformer For T1/E1 Application	Lan Transformer Speed:	10/100/1000/10G Base-TX
Usage:	Electronic	Port:	Quad Port
Mounting Type:	DIP	Hi-pot:	1500Vrms

Product Name:	G3601DG / G3614DG Isolated Single Port Transformer For T1/E1 Application
Lan Transformer Speed:	10/100/1000/10G Base-TX
Usage:	Electronic
Port:	Quad Port
Mounting Type:	DIP
Hi-pot:	1500Vrms

Single Port Ethernet Isolation Transformer G3601DG / G3614DG T1/E1 Application

G3601DG / G3614DG Isolated Single Port transformer for T1/E1 application

Application:

PC computer
PCB Board
Power supplies
Audio
Signal Data Transmission
Electrical Voltage Isolation.

Feature:

RoHS	With RoHS compliant
Speed	100/1000Base-T
Mounting structure	Through-Hole Type
Pin	36pins
Inductance	350 uH
Turns Ratio	1CT:1CT
Operating temperature range	0℃ to +70℃
HI-POT	1500 Vrms
Material	ABS/PBT/PA66/LCP
Phase	Single
Plating	Gold or nickel
Contact Plating	1'-50u'

Dimensions:
