Product Details
Place of Origin: Guangdong,shenzhen
Brand Name: Shareway
Certification: RoHS,ISO9001-2001
Model Number: LPE5047ER101MG
Payment & Shipping Terms
Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel/Tray
Delivery Time: Stock Or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 1kk-pcs/month
Product Name: |
11.99x13.34x6.30mm Flat Copper Wire High Current Inductor LPE5047ER101MG |
Size: |
11.99x13.34x6.30mm |
Inductor: |
High Current Inductor |
Feature: |
Flat Copper Wire |
Type: |
Transformer/inductor |
Sample: |
Free |
Product Name: |
11.99x13.34x6.30mm Flat Copper Wire High Current Inductor LPE5047ER101MG |
Size: |
11.99x13.34x6.30mm |
Inductor: |
High Current Inductor |
Feature: |
Flat Copper Wire |
Type: |
Transformer/inductor |
Sample: |
Free |
11.99x13.34x6.30mm flat copper wire high current inductor LPE5047ER101MG
Feature:
Current Rating:0.11-0.81A
Shielded construction and compact design
High current, low DCR, and high efficiency
Minimized acoustic noise and minimized leakage flux
| MODEL | IND. (μH) |
ND. TOL. |
DCR MAX. (Ohms) |
MAX. RATED* DC CURRENT (Amps) |
SATURATING CURRENT** (Amps) |
| LPE5047ER101MG | 100 | ± 20 % | 0.24 | 0.81 | 0.900 |
| LPE5047ER151MG | 150 | ± 20 % | 0.37 | 0.65 | 0.740 |
| LPE5047ER221MG | 220 | ± 20 % | 0.55 | 0.53 | 0.610 |
| LPE5047ER331MG | 330 | ± 20 % | 0.85 | 0.43 | 0.500 |
| LPE5047ER471MG | 470 | ± 20 % | 1.29 | 0.35 | 0.420 |
| LPE5047ER681MG | 680 | ± 20 % | 1.96 | 0.28 | 0.350 |
| LPE5047ER102MG | 1000 | ± 20 % | 2.38 | 0.26 | 0.290 |
| LPE5047ER152MG | 1500 | ± 20 % | 3.66 | 0.21 | 0.240 |
| LPE5047ER222MG | 2200 | ± 20 % | 5.47 | 0.17 | 0.195 |
| LPE5047ER332MG | 3300 | ± 20 % | 8.48 | 0.14 | 0.160 |
| LPE5047ER472MG | 4700 | ± 20 % | 13.2 | 0.11 | 0.135 |
Dimensions:
