Female RJ45 Modular Vertical / Bottom Entry Model Jack JXD1-0008NL Solder Termination

Name: Female RJ45 Modular Vertical / Bottom Entry Model Jack JXD1-0008NL Solder Termination
Brand: SHAREWAY TECHNOLOGY CO., LTD.
SKU: JXD1-0008NL
Price: 49.10 USD
Availability: InStock

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Model Number: JXD1-0008NL

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: Supportive

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 1kk-pcs/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                dual rj45 jack, 8 port rj45 connector


Product Name:	JXD1-0008NL Vertical And Bottom-Entry Model RJ45 Female Jack	Orientation:	90° Angle (Right)
Termination:	Solder	LED Color:	Green - Yellow
Number Of Cores Per Jack:	4	Shielding:	Shielded, EMI Finger

Product Name:	JXD1-0008NL Vertical And Bottom-Entry Model RJ45 Female Jack
Orientation:	90° Angle (Right)
Termination:	Solder
LED Color:	Green - Yellow
Number Of Cores Per Jack:	4
Shielding:	Shielded, EMI Finger

Female RJ45 Modular Vertical / Bottom Entry Model Jack JXD1-0008NL Solder Termination

JXD1-0008NL Vertical And Bottom-Entry Model RJ45 Female Jack

Description:

10/100M Single Port Transformer Modules
10-100M Single Port Transf. Mods.
10-100M 2×1 Port Tab
1000M 1×4 Port Transf. Modules
10-100M Single Port Dual USB(Height=29.4MM)
10-100M Single Port Vertical
10-100M PC Card Lan Magnetic

Electronical Specifications:

0 Turn Ratio @100KHz: (P1-P2):(J1-J2)=1:1±5% (P3-P6):(J3-J6)=1:1±5%
0 Primary Inductance: 350uH MIN @100KHz, 0.1V 8mA DC Bias
0 DC Resistance: (J1-J2):(J3-J6) 1.2 OHMS MAX
0 COMMON TO COMMON MODE ATTENUATION: 1-100MHz -30dB MIN
Isolation: PHY Side to Line Side: 2250VDC

Dimension:
