Product Details
Place of Origin: Guangdong,shenzhen
Brand Name: Shareway
Certification: RoHS,ISO9001-2001
Model Number: H2050DG
Payment & Shipping Terms
Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel/Tray
Delivery Time: Stock Or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 1kk-pcs/month
Part Number: |
H2050DG Through Hole Power Over Ethernet POE Pulse Transformers |
Mounting Structure: |
Through Hole |
Pin No.: |
20Pins |
Length: |
21.0mm |
Width: |
10.0mm |
Height: |
6.75mm |
Part Number: |
H2050DG Through Hole Power Over Ethernet POE Pulse Transformers |
Mounting Structure: |
Through Hole |
Pin No.: |
20Pins |
Length: |
21.0mm |
Width: |
10.0mm |
Height: |
6.75mm |
H2050DG Through Hole Power over Ethernet POE Pulse Transformers
Description:
Electrical Specifications @25°C
| Part Number |
OCL(uH Min) With 8mA DC Bias |
Turns Ratio (±5%) |
Insertion Loss (dB Max) 0.5-100MHz |
Return Loss 0.5-30MHz |
Return Loss 30.1-60MHz |
Return Loss 60.1-80MHz |
Cross talk 0.5-40MHz |
Cross talk 40.1-100MHz |
CMRR (dB Min) 0.5-100MHz |
HI-POT (Vrms) |
| H2050DG | 350 | 1CT:1CT | -1.1 | -18 | -18+20*log(f/30) | -12 | -35 | -33+20*log(f/50) | -30 | 4000 |
Dimensions:
