Name: 4.7uH 0.76A SMD Power Inductor Reflow Soldering NRV2010T4R7MGF Halogen Free
Brand: SHAREWAY TECHNOLOGY CO., LTD.
SKU: NRV2010T4R7MGF
Price: 0.30 USD
Availability: InStock

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Model Number: NRV2010T4R7MGF

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: Supportive

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 1kk-pcs/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                high current power inductors, dc dc converter inductor


Product Name:	4.7uH±20%, 0.76A, 2.0x2.0x1.0mm Power Inductor NRV2010T4R7MGF	Size:	2.0x2.0x1.0mm
Inductance:	4.7uH±20%	Current:	0.76A
Halogen Free:	Yes	Soldering:	Reflow

Product Name:	4.7uH±20%, 0.76A, 2.0x2.0x1.0mm Power Inductor NRV2010T4R7MGF
Size:	2.0x2.0x1.0mm
Inductance:	4.7uH±20%
Current:	0.76A
Halogen Free:	Yes
Soldering:	Reflow

4.7uH 0.76A SMD Power Inductor Reflow Soldering NRV2010T4R7MGF Halogen Free

4.7uH±20%, 0.76A, 2.0x2.0x1.0mm Power Inductor NRV2010T4R7MGF

Description:

Part number	NRV2010T4R7MGF
Brand	Shareway
Inductance	4.7 uH ± 20 %
Size (mm)	2.0x2.0
Rated Current (max)	0.76 A
Saturation Current (max)	0.76 A (⊿L=30%)
Saturation Current (typ)	0.81 A (⊿L=30%)
Temperature Rise Current (max)	0.82 A (⊿T=40℃)
Temperature Rise Current (typ)	0.93 A (⊿T=40℃)
DC Resistance (max)	0.384 Ω
DC Resistance (typ)	0.32 Ω
LQ Measuring Frequency	100 kHz
Operating Temp. Range	-25 to +120 ℃ (Including-self-generated heat)

Dimensions:

4.7uH 0.76A SMD Power Inductor Reflow Soldering NRV2010T4R7MGF Halogen Free 0
