Name: NR Series SMD Power Inductor Shielded Molding Buzzer NRV2010T1R5MGF For Driver
Brand: SHAREWAY TECHNOLOGY CO., LTD.
SKU: NRV2010T1R5MGF
Price: 0.30 USD
Availability: InStock

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Model Number: NRV2010T1R5MGF

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: Supportive

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 1kk-pcs/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                wire wound chip inductors, high current power inductors


Product Name:	NRV2010T1R5MGF Shielded Molding Buzzer Power Inductor NR Series	Usage:	Driver
Series:	NR Series	Inductor:	Molding Buzzer Power Inductor
RoHS:	Yes	Saturation Current (max):	1.35 A

Product Name:	NRV2010T1R5MGF Shielded Molding Buzzer Power Inductor NR Series
Usage:	Driver
Series:	NR Series
Inductor:	Molding Buzzer Power Inductor
RoHS:	Yes
Saturation Current (max):	1.35 A

NR Series SMD Power Inductor Shielded Molding Buzzer NRV2010T1R5MGF For Driver

NRV2010T1R5MGF Shielded Molding Buzzer Power Inductor NR series

Description:

Part number	NRV2010T1R5MGF
Brand	Shareway
Inductance	1.5 uH ± 20 %
Case Size (mm)	2.0x2.0
Rated Current (max)	1.35 A
Saturation Current (max)	1.35 A (⊿L=30%)
Saturation Current (typ)	1.45 A (⊿L=30%)
Temperature Rise Current (max)	1.45 A (⊿T=40℃)
Temperature Rise Current (typ)	1.65 A (⊿T=40℃)
DC Resistance (max)	0.12 Ω
DC Resistance (typ)	0.1 Ω
LQ Measuring Frequency	100 kHz
Operating Temp. Range	-25 to +120 ℃ (Including-self-generated heat)
Temperature characteristic (Inductance change)	± 20 %
RoHS Compliance (10 subst.)	Yes
REACH Compliance (201 subst.)	Yes
Halogen Free	Yes
Soldering	Reflow

Dimensions:
