Product Details
Place of Origin: Guangdong,shenzhen
Brand Name: Shareway
Certification: RoHS,ISO9001-2001
Model Number: NS10145T101MNA
Payment & Shipping Terms
Minimum Order Quantity: 500/1000
Price: Supportive
Packaging Details: Reel/Tray
Delivery Time: Stock Or 3 weeks
Payment Terms: TT,Paypal,West Union
Supply Ability: 1kk-pcs/month
Part Number: |
NS10145T101MNA NS Series Inductor For Communication Transmission |
Application: |
Communication Transmission |
Inductor: |
NS Series Inductor |
Current: |
High Current |
Inductance: |
100 UH ± 20 % |
Material: |
Alloyed |
Part Number: |
NS10145T101MNA NS Series Inductor For Communication Transmission |
Application: |
Communication Transmission |
Inductor: |
NS Series Inductor |
Current: |
High Current |
Inductance: |
100 UH ± 20 % |
Material: |
Alloyed |
NS10145T101MNA NS series Inductor for Communication Transmission
Description:
Inductance | 100 uH ± 20 % |
Case Size (mm) | 10.1x10.1 |
Rated Current (max) | 1.25 A |
Saturation Current (max) | 1.29 A (⊿L=30%) |
mperature Rise Current (max) | 1.25 A (⊿T=40℃) |
DC Resistance (max) | 0.24 Ω |
DC Resistance (typ) | 0.2 Ω |
LQ Measuring Frequency | 100 kHz |
Self Resonant Frequency (min) | 6 MHz |
Operating Temp. Range | -40 to +125 ℃ (Including-self-generated heat) |
Temperature characteristic (Inductance change) |
± 15 % |
RoHS Compliance (10 subst.) | Yes |
REACH Compliance (201 subst.) | Yes |
Soldering | Reflow |
Dimensions:
