Product Details
Place of Origin: China
Brand Name: Shareway
Model Number: ATPL-511PR
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: Supportive
Delivery Time: 3-4weeks
Payment Terms: L/C, T/T
Supply Ability: 10000PCS/month
Length: |
15.24±0.5mm |
Width: |
13.6±0.5mm |
Height: |
5.7±0.5mm |
Length: |
15.24±0.5mm |
Width: |
13.6±0.5mm |
Height: |
5.7±0.5mm |
ELECTRICAL CHARACTERISTICS @25℃:
1.Insulation HI-POT: 1500Vrms/0.5mA,60Sec.
2.Turn Ratio(±5%):1CT:1CT.
3.OCL:(@100kHz,0.1Vrms,8mA DC Bias)；120uH MIN.
(@100kHz,0.1Vrms,15mA DC Bias)；100uH MIN.
4.CROSS TALK(dB MIN):1-500Mhz:-25.
5.Operating Temperature Range:0℃~+70℃.
