Product Name: |
750316093 Low Profile GDT Gate Drive Transformers For Medical Devices |
Usage: |
For Medical Devices |
Mount: |
Surface Mount |
Product Type:: |
GDT Gate Drive Transformers |
Operating Temperature Range: |
–40 °C To +125 °C |
Inductance: |
1710 UH |
Package: |
Cut Tape /MouseReel/ Reel |
Product Name: |
750316093 Low Profile GDT Gate Drive Transformers For Medical Devices |
Usage: |
For Medical Devices |
Mount: |
Surface Mount |
Product Type:: |
GDT Gate Drive Transformers |
Operating Temperature Range: |
–40 °C To +125 °C |
Inductance: |
1710 UH |
Package: |
Cut Tape /MouseReel/ Reel |
750316093 Low profile GDT Gate Drive Transformers for Medical devices
Characteristics
Applications
ELECTRICAL SPECIFICATTONS 回 25°C unless otherwise noted:
|
PARAMETER |
TEST CONDITIONS |
VALUE |
|
D.C, RESISTANCE 5-8 |
tie(6+7), @20DC |
0.649 ohms ±15% |
|
D.C, RESISTANCE 1-3 |
@20°C |
0.594 ohms 土 15% |
|
D.C, RESISTANCE 2-4 |
@20°C |
0.677 ohms ±15% |
|
INDUCTANCE 5-8 |
tie(6+7), 10kHz, lOOmVAC, Ls |
1.71 mH min. |
|
LEAKAGE INDUCTANCE 5-8 |
tie(6+7, 1+2 + 3+4), 100kHz, WOmVAC, Ls |
0.5uH typ., 1.5uH max. |
|
DISTRIBUTED CAPACITANCE 5-8 |
tie(6+7), lOOmVAC, Cs |
16.0pF typ. |
|
INTERWINDING CAPACITANCE 1-8 |
tie(6+7), 100kHz, lOmVAC, Cs |
70.0pF typ., 100.0pF max. |
|
INTERWINDING CAPACITANCE 2-8 |
tie(6+7), 100kHz, lOmVAC, Cs |
70.0pF typ., 100.0pF max. |
|
DIELECTRIC 1-8 |
tie(6+7, 2+3), 1500VAC, 1 second |
1500VAC, 1 minute |
|
TURNS RATIO |
(1-3):(2-4) |
1:1, 土 1% |
|
TURNS RATIO |
(1—3):(5—8), tie(6+7) |
1:1, ±1% |
Shape and Dimensions:
Product picture:
750316093 Low profile GDT Gate Drive Transformers for Medical devices
