750320340 SMD Push Pull Transformers For Industrial Automation

Product Details

Place of Origin: Guangdong China

Brand Name: Shareway

Certification: CE UL RoHS ISO9001:2008

Model Number: 750320340

Payment & Shipping Terms

Minimum Order Quantity: 100pcs

Price: Supportive

Packaging Details: 500 parts per full reel

Delivery Time: Stock or 3-4 weeks

Payment Terms: TT,Paypal

Supply Ability: 5000K.PCS/Month

Get Best Price
Highlight:

Industrial Automation SMD Push Pull Transformers

,

Surface Mount Push Pull Transformers

,

Low Profile SMD Transformers

Product Name:
750320340 SMD Push-Pull Transformers For Industrial Automation
Usage:
For Industrial Automation
Mount:
Surface Mount
Product Type::
Push-Pull Transformers
Operating Temperature Range:
-40 °C Up To +125 °C
Inductance:
200 UH
Package:
Cut Tape /MouseReel/ Reel
Product Name:
750320340 SMD Push-Pull Transformers For Industrial Automation
Usage:
For Industrial Automation
Mount:
Surface Mount
Product Type::
Push-Pull Transformers
Operating Temperature Range:
-40 °C Up To +125 °C
Inductance:
200 UH
Package:
Cut Tape /MouseReel/ Reel
750320340 SMD Push Pull Transformers For Industrial Automation

750320340 SMD Push-Pull Transformers for Industrial automation


Characteristics

  1. Small size
  2. Surface mount
  3. Low profile
  4. Operating temp: -40°C to 125°C





Applications

  1. Isolated interface power supply for CAN, RS-485, RS-422, RS-232, SPI, I2C, lower-power LAN
  2. Industrial automation
  3. Process control
  4. Medical equipment
  5. PLC analog and digital I/O modules
  6. Isolated gate driver power supplies
  7. AC motor drives
  8. Uninterruptible power supplies (UPS)
  9. Solar inverters
  10. Polyphase energy meters
  11. Protection relays and IEDs



Electrical Properties:

Properties   Test conditions Value Unit Tol
Inductance L N1+N2/ 100 kHz/10 mVAC 200 uH min.
Turns Ratio n N1+N2 : N3+N4 1:3.5
DC Resistance 1 RDC 1 N1+N2/ 20 °C 0.41 Ω max
DC Resistance 2 RDC 2 N3+N4/ 20 °C 1.5 Ω max
Voltage-Time ∫Udt N1/ bipolar waveform 16 Vµs
Insulation Test Voltage VT N1,2 => N3,4 6000 V (AC)





Shape and Dimensions:

750320340 SMD Push Pull Transformers For Industrial Automation 0





Product picture:

750320340 SMD Push Pull Transformers For Industrial Automation 1



750320340 SMD Push-Pull Transformers for Industrial automation
