Product Details
Place of Origin: Guangdong China
Brand Name: Shareway
Certification: CE UL RoHS ISO9001:2008
Model Number: 74485540080
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: Supportive
Packaging Details: 500 parts per full reel
Delivery Time: Stock or 3-4 weeks
Payment Terms: TT,Paypal
Supply Ability: 5000K.PCS/Month
Product Name: |
Very Low RDC SMD CFWI Coupled Flatwire Inductor 74485540080 |
Usage: |
For High Power Switching Regulators |
Mount: |
Surface Mount |
Product Type:: |
CFWI Coupled Flatwire Inductor |
Operating Temperature Range: |
-40 °C Up To +150 °C |
Inductance: |
0.8 µH |
Package: |
Cut Tape /MouseReel/ Reel |
Product Name: |
Very Low RDC SMD CFWI Coupled Flatwire Inductor 74485540080 |
Usage: |
For High Power Switching Regulators |
Mount: |
Surface Mount |
Product Type:: |
CFWI Coupled Flatwire Inductor |
Operating Temperature Range: |
-40 °C Up To +150 °C |
Inductance: |
0.8 µH |
Package: |
Cut Tape /MouseReel/ Reel |
Very low RDC SMD CFWI Coupled Flatwire Inductor 74485540080
Characteristics
Applications
Electrical Properties:
| Properties | Test conditions | Value | Unit | Tol. | |
| Inductance 1 | L 1 | 100 kHz/ 1 mA | 0.8 | µH | ±20% |
| Inductance 2 | L 2 | 100 kHz/ 1 mA | 0.8 | µH | ±20% |
| Rated Current 1 | I R 1 | ΔT = 50 K | 28 | A | max. |
| Rated Current 2 | I R 2 | ΔT = 50 K | 28 | A | max |
| Saturation Current 1 | I SAT 1 | |ΔL/L| < 30 % | 62 | A | typ. |
| Saturation Current 2 | I SAT 2 | |ΔL/L| < 30 % | 62 | A | typ |
| DC Resistance 1 | RDC | @ 20 °C | 1.6 | mΩ | ±10% |
| DC Resistance 2 | RDC | @ 20 °C | 1.6 | mΩ | ±10% |
| Turns Ratio | n | 1 : 1 | |||
| Rated Voltage | UR | 80 | V | max |
Shape and Dimensions:
Product picture:
Very low RDC SMD CFWI Coupled Flatwire Inductor 74485540080
