Product Details
Place of Origin: China
Brand Name: Shareway
Model Number: 74089
Payment & Shipping Terms
Minimum Order Quantity: 100
Price: supportive
Delivery Time: 3-4weeks
Payment Terms: L/C, T/T
Supply Ability: 10000PCS/month
Length: |
21mm |
Width: |
21mm |
Height: |
22mm |
Frequency: |
High Frequency |
Product Name: |
Ferrite Core Smps Transformer |
Core Material: |
Ferrite Core Mn-Zn |
Length: |
21mm |
Width: |
21mm |
Height: |
22mm |
Frequency: |
High Frequency |
Product Name: |
Ferrite Core Smps Transformer |
Core Material: |
Ferrite Core Mn-Zn |
1. Primary / Secondary Insulation ≥ 4000V • Primary / Auxiliary Insulation ≥ 1500V
2. Creepage distance Primary / Secondary ≥ 8mm
3. Ambient temperature < 50°C
4. Output Power maximum: 20w
5. Inductance(+/-10%):1300 uH
6. Input voltage: 85 - 265Vrms
7. Frequency:132kHz
