7443340680 Offline Flyback Transformer Through Hole For Industrial Telecom

Product Details

Place of Origin: Guangdong China

Brand Name: Shareway

Certification: CE UL RoHS ISO9001:2008

Model Number: 7443340680

Payment & Shipping Terms

Minimum Order Quantity: 100pcs

Price: Supportive

Packaging Details: 500 parts per full reel

Delivery Time: Stock or 3-4 weeks

Payment Terms: TT,Paypal

Supply Ability: 5000K.PCS/Month

Get Best Price
Highlight:

7443340680

,

Through hole Offline Flyback Transformer

,

Industrial Telecom Offline Flyback Transformer

Product Name:
7443340680 Offline Flyback Transformers For Industrial Telecom
Usage:
For Industrial Telecom
Mount:
Through-hole
Product Type::
SMPS Flyback Transformer
Operating Temperature Range:
-40°C To +125°C
Inductance:
1.95 MH
Package:
Cut Tape /MouseReel/ Reel
Product Name:
7443340680 Offline Flyback Transformers For Industrial Telecom
Usage:
For Industrial Telecom
Mount:
Through-hole
Product Type::
SMPS Flyback Transformer
Operating Temperature Range:
-40°C To +125°C
Inductance:
1.95 MH
Package:
Cut Tape /MouseReel/ Reel
7443340680 Offline Flyback Transformer Through Hole For Industrial Telecom

7443340680 Offline Flyback Transformers For Industrial Telecom​


Characteristics

  1. Switching Frequency 50-150kHz
  2. Low real estate
  3. Extended Rails
  4. Reinforced Insulation



Applications

  1. Offline Switching Power
  2. Power Electronics
  3. Electronic Ballasts
  4. White Goods
  5. Industrial Controls
  6. Industrial Telecom
  7. Metering
  8. LED Lighting





Electrical Properties:

Properties   Test conditions Value Unit t Tol.
Inductance L N1/ 10 kHz/ 100 mV 1.95 mH ±10%
Turns Ratio n N1 : N2 : N3 2.56:1:0.67
Saturation Current I SAT N1/ |ΔL/L| < 20 % 320 mA typ
DC Resistance 1 RDC 1 N1/ 20 °C 3.96 Ω ±10%
DC Resistance 2 RDC 2 N2/ 20 °C 0.75 Ω ±20%
DC Resistance 3 RDC 3 N3/ 20 °C 1.74 Ω ±10%
Leakage Inductance L S N1/ 100 kHz/ 100 mV 33 µH max.
Insulation Test Voltage VT N1,3 => N2 3600 V (AC)





Shape and Dimensions:

7443340680 Offline Flyback Transformer Through Hole For Industrial Telecom 0





Product picture:

7443340680 Offline Flyback Transformer Through Hole For Industrial Telecom 1



7443340680 Offline Flyback Transformers For Industrial Telecom​
