SMD BMS Signal Transformer Two Channels With Choke SM91509AL
SMD BMS Signal Transformer Two channels with choke SM91509AL
Electrical Specifications @ 25 °C
OCL
(100 kHz, 0.1 V, (-40 °C ~ +125 °C)
........................................ 600 µH min.
Leakage Inductance (100 kHz, 0.1 V)
........................................ 0.5 µH max.
DCR
Cable Side......................... 1.2 Ω max.
Chip Side........................... 1.2 Ω max.
Turns Ratio ...............................1:1 ±2 %
Insertion Loss
4 MHz............................-0.25 dB max.
Return Loss (Z out = 100 Ω)
4 MHz................................-22 dB min.
Cross Talk (Between each channel)
1-10 MHz...........................-50 dB min.
10-100 MHz
................... -50+20*LOG10 (f/10 MHz)
Common Mode Rejection Ratio
1~200 MHz........................-30 dB min.
Hi-Pot (1 mA, 60 sec.)
...................... 4300 Vdc or 3100 Vrms
Design Construction .............. Functional
Insulation
Working Voltage ......................1600 Vdc
Operating Temperature
....
-40 to +125 °C
Storage Temperature.......-50 to +125 °C
Moisture Sensitivity Level.....................1
Shape and Dimensions:
Product picture:
SMD BMS Signal Transformer Two channels with choke SM91509AL
