Home > products > Small Signal Transformer > 16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic

16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic

Product Details

Place of Origin: Guangdong,shenzhen

Brand Name: Shareway

Certification: RoHS,ISO9001-2001

Model Number: TG10-DA1NSLF, TG10-DA2N5LF

Payment & Shipping Terms

Minimum Order Quantity: 500/1000

Price: 0.4682US$~0.9543US$

Packaging Details: Reel/Tray

Delivery Time: Stock Or 3 weeks

Payment Terms: TT,Paypal,West Union

Supply Ability: 100k pcs/month

Get Best Price
Highlight:

16 Pin Digital Audio Transformer

,

Cirrus Logic Digital Audio Transformer

,

Single Dual Channel Shielded Transformer

Product Name:
Digital Audio Transformer For Cirrus Logic
Number Of Lines:
2
Inductance:
128µH @ 100kHz
Current Rating:
300mA
Operating Temperature:
-40°C ~ 125°C
Mounting Type:
Surface Mount
Isolation Voltage:
1500V
Bandwidth:
10kHz~ 200MHz
Product Name:
Digital Audio Transformer For Cirrus Logic
Number Of Lines:
2
Inductance:
128µH @ 100kHz
Current Rating:
300mA
Operating Temperature:
-40°C ~ 125°C
Mounting Type:
Surface Mount
Isolation Voltage:
1500V
Bandwidth:
10kHz~ 200MHz
16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic

Digital Audio Transformer for Cirrus Logic, Single and Dual Channel shielded transformer for Digital Audio




Single and Dual Channel shielded transformer for Digital Audio


  • Designed for Cirrus Logic Digital Audio Transceivers
  • Robust patented open frame construction
  • Excellent performance for professional digital audio AES/EBU applications
  • 100% RoHS



Typical Applications

  • Power supply system
  • Signal and sensor lines
  • Current compensated choke for data and signal lines
  • Suppression of common-mode noise

Product details:

Part Number Trader Part number Package Channels Operating temperature range Turns Ratio Bandwidth Cw/w2 Isolation
STD0601 TG10-DA1NSLF 6-Pin 1 -40~+85℃ 1:1 10kHz~200MHz 9pF max 1500Vrms
STD1601 TG10-DA2N5LF 16-pin 2 -40~+85℃ 1:1, 1:1 10kHz~200MHz 9pF max 1500Vrms


Real Product Photo:

16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic 0

16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic 1




Mechanical Dimensions:

Type A:

16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic 2

Type B:

16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic 3

Schematics:

16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic 4
16 Pin Digital Audio Transformer Single Dual Channel For Cirrus Logic 5
